Involute Spline Shafts (SV)
Other Products
Economical, commonly used worm wheels that have broad utility. Available with a large selection of modules and number of teeth.
Please note that all J-Series, E-Series, F-Series, H-Series, HJ-Series & S-Series products are made-to-order, noncancellable, and non-returnable.
Please note that all J-Series, E-Series, F-Series, H-Series, HJ-Series & S-Series products are made-to-order, noncancellable, and non-returnable.
Item # |
Sell Price |
CAD |
Module |
No. of teeth |
Shaft Diameter / Bore (A) |
Shaft Length Left (F') |
Outer Diameter (D) |
Internal ID |
Sell Price 1 Value |
|---|---|---|---|---|---|---|---|---|---|
| SV17-170 | $119.89 |
CAD
N/A
|
Module N/A 1.667 | No. of teeth N/A 8 | Shaft Diameter / Bore (A) N/A 0.512 in13 mm | Shaft Length Left (F') N/A 0.787 in20 mm | Outer Diameter (D) N/A 0.656 in16.67 mm |
Internal ID
N/A
30377 |
119.89 |
| SV20-200 | $168.42 |
CAD
N/A
|
Module N/A 1.667 | No. of teeth N/A 10 | Shaft Diameter / Bore (A) N/A 0.591 in15 mm | Shaft Length Left (F') N/A 0.787 in20 mm | Outer Diameter (D) N/A 0.774 in19.67 mm |
Internal ID
N/A
30378 |
168.42 |
| SV25-250 | $240.84 |
CAD
N/A
|
Module N/A 1.667 | No. of teeth N/A 13 | Shaft Diameter / Bore (A) N/A 0.787 in20 mm | Shaft Length Left (F') N/A | Outer Diameter (D) N/A 0.971 in24.67 mm |
Internal ID
N/A
30379 |
240.84 |
| SV30-300 | $311.59 |
CAD
N/A
|
Module N/A 1.667 | No. of teeth N/A 16 | Shaft Diameter / Bore (A) N/A 0.984 in25 mm | Shaft Length Left (F') N/A | Outer Diameter (D) N/A 1.168 in29.67 mm |
Internal ID
N/A
30380 |
311.59 |
