CP Thermal Refined Ground Racks (KRGCP - KRGCPF - KRGCPD)
CP Rack & Pinions
Please note that all J-Series, E-Series, F-Series, H-Series, HJ-Series & S-Series products are made-to-order, noncancellable, and non-returnable.
Please note that all J-Series, E-Series, F-Series, H-Series, HJ-Series & S-Series products are made-to-order, noncancellable, and non-returnable.
Item # |
Sell Price |
CAD |
Module |
No. of Teeth |
Effective No. of Teeth |
Shape |
Total Length Rack (A) |
Face Width (B) |
Height (C) |
Height To Pitch Line (D) |
Internal ID |
Sell Price 1 Value |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KRGCP5-100 | $121.34 |
CAD
N/A
|
Module N/A 1.5915 | No. of Teeth N/A | Effective No. of Teeth N/A 18 | Shape N/A R1 | Total Length Rack (A) N/A 3.858 in98 mm | Face Width (B) N/A 0.591 in15 mm | Height (C) N/A 0.787 in20 mm | Height To Pitch Line (D) N/A 0.725 in18.41 mm |
Internal ID
N/A
4793 |
121.34 |
| KRGCP5-500 | $9,876.54 |
CAD
N/A
|
Module N/A 1.5915 | No. of Teeth N/A | Effective No. of Teeth N/A 99 | Shape N/A R1 | Total Length Rack (A) N/A 19.882 in505 mm | Face Width (B) N/A 0.591 in15 mm | Height (C) N/A 0.787 in20 mm | Height To Pitch Line (D) N/A 0.725 in18.41 mm |
Internal ID
N/A
4794 |
9876.54 |
| KRGCPD5-500 | $9,876.54 |
CAD
N/A
|
Module N/A 1.5915 | No. of Teeth N/A 100 | Effective No. of Teeth N/A | Shape N/A RD | Total Length Rack (A) N/A 19.685 in500 mm | Face Width (B) N/A 0.591 in15 mm | Height (C) N/A 0.787 in20 mm | Height To Pitch Line (D) N/A 0.725 in18.41 mm |
Internal ID
N/A
4796 |
9876.54 |
| KRGCPF5-1000 | $800.78 |
CAD
N/A
|
Module N/A 1.5915 | No. of Teeth N/A 200 | Effective No. of Teeth N/A | Shape N/A RF | Total Length Rack (A) N/A 39.370 in1000 mm | Face Width (B) N/A 0.591 in15 mm | Height (C) N/A 0.787 in20 mm | Height To Pitch Line (D) N/A 0.725 in18.41 mm |
Internal ID
N/A
4801 |
800.78 |
| KRGCPF5-500 | $489.46 |
CAD
N/A
|
Module N/A 1.5915 | No. of Teeth N/A 100 | Effective No. of Teeth N/A | Shape N/A RF | Total Length Rack (A) N/A 19.685 in500 mm | Face Width (B) N/A 0.591 in15 mm | Height (C) N/A 1.378 in35 mm | Height To Pitch Line (D) N/A 1.292 in32.82 mm |
Internal ID
N/A
4803 |
489.46 |
| KRGCPFD5-1000J | $861.70 |
CAD
N/A
|
Module N/A 1.5915 | No. of Teeth N/A 100 | Effective No. of Teeth N/A | Shape N/A RD | Total Length Rack (A) N/A 39.370 in1000 mm | Face Width (B) N/A 0.591 in15 mm | Height (C) N/A 0.787 in20 mm | Height To Pitch Line (D) N/A 0.725 in18.41 mm |
Internal ID
N/A
4810 |
861.7 |
| KRGCPFD5-500J | $543.70 |
CAD
N/A
|
Module N/A 1.5915 | No. of Teeth N/A 200 | Effective No. of Teeth N/A | Shape N/A RD | Total Length Rack (A) N/A 19.685 in500 mm | Face Width (B) N/A 0.591 in15 mm | Height (C) N/A 0.787 in20 mm | Height To Pitch Line (D) N/A 0.725 in18.41 mm |
Internal ID
N/A
4812 |
543.7 |
| KRGCP10-100 | $169.95 |
CAD
N/A
|
Module N/A 3.1831 | No. of Teeth N/A | Effective No. of Teeth N/A 8 | Shape N/A R1 | Total Length Rack (A) N/A 3.858 in98 mm | Face Width (B) N/A 1.181 in30 mm | Height (C) N/A 1.378 in35 mm | Height To Pitch Line (D) N/A 1.253 in31.82 mm |
Internal ID
N/A
4791 |
169.95 |
| KRGCP10-500 | $9,876.54 |
CAD
N/A
|
Module N/A 3.1831 | No. of Teeth N/A | Effective No. of Teeth N/A 49 | Shape N/A R1 | Total Length Rack (A) N/A 19.882 in505 mm | Face Width (B) N/A 1.181 in30 mm | Height (C) N/A 1.378 in35 mm | Height To Pitch Line (D) N/A 1.253 in31.82 mm |
Internal ID
N/A
4792 |
9876.54 |
| KRGCPD10-500 | $9,876.54 |
CAD
N/A
|
Module N/A 3.1831 | No. of Teeth N/A 50 | Effective No. of Teeth N/A | Shape N/A RD | Total Length Rack (A) N/A 19.685 in500 mm | Face Width (B) N/A 1.181 in30 mm | Height (C) N/A 1.378 in35 mm | Height To Pitch Line (D) N/A 1.253 in31.82 mm |
Internal ID
N/A
4795 |
9876.54 |
| KRGCPF10-1000 | $1,169.15 |
CAD
N/A
|
Module N/A 3.1831 | No. of Teeth N/A 100 | Effective No. of Teeth N/A | Shape N/A RF | Total Length Rack (A) N/A 39.370 in1000 mm | Face Width (B) N/A 1.181 in30 mm | Height (C) N/A 1.378 in35 mm | Height To Pitch Line (D) N/A 1.253 in31.82 mm |
Internal ID
N/A
4797 |
1169.15 |
| KRGCPF10-500 | $669.55 |
CAD
N/A
|
Module N/A 3.1831 | No. of Teeth N/A 50 | Effective No. of Teeth N/A | Shape N/A RF | Total Length Rack (A) N/A 19.685 in500 mm | Face Width (B) N/A 1.181 in30 mm | Height (C) N/A 1.378 in35 mm | Height To Pitch Line (D) N/A 1.292 in32.82 mm |
Internal ID
N/A
4799 |
669.55 |
| KRGCPFD10-1000J | $1,246.40 |
CAD
N/A
|
Module N/A 3.1831 | No. of Teeth N/A 100 | Effective No. of Teeth N/A | Shape N/A RD | Total Length Rack (A) N/A 39.370 in1000 mm | Face Width (B) N/A 1.181 in30 mm | Height (C) N/A 1.181 in30 mm | Height To Pitch Line (D) N/A 1.253 in31.82 mm |
Internal ID
N/A
4806 |
1246.4 |
| KRGCPFD10-500J | $740.90 |
CAD
N/A
|
Module N/A 3.1831 | No. of Teeth N/A 50 | Effective No. of Teeth N/A | Shape N/A RD | Total Length Rack (A) N/A 19.685 in500 mm | Face Width (B) N/A 1.181 in30 mm | Height (C) N/A 1.181 in30 mm | Height To Pitch Line (D) N/A 1.253 in31.82 mm |
Internal ID
N/A
4808 |
740.9 |
